Aiphone Chime Com 2 CCS-1A Set Single-Door Answering Intercom System

Aiphone Chime Com 2 CCS-1A Set Single-Door Answering Intercom System

New: A brand-new, unused, undamaged item in its original packaging. Packaging is Distressed.

The Aiphone Chime Com 2 CCS-1A is a reliable single-door intercom system designed for secure communication with visitors before granting access. It features a straightforward design with essential functionalities for residential and commercial security.

Product Specifications:

• Brand: Aiphone
• Model: CCS-1A
• Power Source: 12~16V AC (use PT-1210NA)
• Communication: Push-to-talk (simplex)
• Wire Type:
  • Door Station to Master Station: 245′ (22AWG)
  • Door Station to Master Station: 490′ (18AWG)
• UPC: 790143102050

Key Features:

• Single-Door Communication: Allows secure communication with visitors at a single entry point.
• Backlit Call Button: Enhances visibility, especially in low-light conditions.
• Listening Feature: Enables the master intercom operator to receive audio from the door intercom at any time.
• Adjustable Volume: Audio and chime volumes can be adjusted to suit the environment.

Applications:

• Residential Security: Ideal for homeowners wanting to communicate with visitors before allowing entry.
• Commercial Buildings: Suitable for small offices or retail stores to monitor entrance points.
• Educational Institutions: Can be used in schools to control access to buildings and ensure safety.

General  Installation and Setup:

1. Preparation:
   • Ensure the power supply (12~16V AC) and necessary tools are available.
   • Gather tools such as a screwdriver, drill, and appropriate wiring (22AWG or 18AWG).
2. Mounting the Door Station:
   • Choose a suitable location near the entry point for the door station.
   • Use the provided screws to mount the door station securely.
3. Mounting the Master Station:
   • Select a convenient indoor location for the master station.
   • Mount the master station using the provided screws.
4. Wiring the System:
   • Run the wiring from the door station to the master station, ensuring it does not exceed the maximum distance (245′ for 22AWG or 490′ for 18AWG).
   • Connect the wires according to the wiring diagram in the user manual.
5. Powering the System:
   • Connect the system to the power supply using the PT-1210NA transformer.
   • Ensure all connections are secure and that the power source matches the required voltage (12~16V AC).
6. Testing and Configuration:
   • Power on the system and press the call button on the door station.
   • Test the push-to-talk communication to ensure the master station can hear and respond to the door station.
   • Adjust the audio and chime volumes as needed for optimal performance.

Maintenance Tips:

• Regular Testing: Periodically test the system to ensure all components function correctly.
• Cleaning: Keep the door station and master station clean to ensure clear audio transmission.
• Check Wiring: Regularly inspect the wiring for signs of wear or damage and replace if necessary.

Safety and Compliance:

• Handling: Handle the system components with care during installation to avoid damaging internal parts.
• Electrical Safety: Ensure all wiring is correctly connected and insulated to prevent electrical hazards.
• Compliance: Follow local building and electrical codes during installation to ensure compliance and safety.

The Aiphone Chime Com 2 CCS-1A Single-Door Answering System provides a reliable and user-friendly solution for secure communication at entry points. Its backlit call button, listening feature, and adjustable volume make it ideal for various applications in residential, commercial, and educational settings. Proper installation and regular maintenance will ensure optimal performance and long-term reliability.
