Dayton 48ZJ83 Industrial motor 208-230/460V 1750 RPM 1HP NEMA Premium CC 030A

Dayton 48ZJ83 Industrial motor CC 030A 208-230/460V 1750 RPM 1HP NEMA Premium

Condition: New, unused, attached to the original board, no original packaging

The Dayton 48ZJ83 is a high-performance industrial motor designed for reliability and efficiency in demanding applications. It offers versatile operation at both 60 Hz and 50 Hz, making it suitable for various industrial environments.

Product Specifications:

General Information:

• Brand: Dayton
• Model Number: 48ZJ83
• Condition: New, unused, attached to the original board, no original packaging
• Weight: 30 lbs
• Country of Manufacture: Mexico (with imported and domestic components)

Electrical Specifications:

• Insulation Class: F
• Duty: Continuous (CONT)
• Design: B
• Shaft End Bearing: 6205-27-J/C3
• Opposite End Bearing: 6203-2z-J/C3
• Frame: 56H
• Phase: 3
• Maximum Ambient Temperature: 40°C

Section 1: 60 Hz Operation:

• Horsepower (HP): 1
• Speed (RPM): 1750
• Service Factor (SF): 1.25
• Efficiency (NEMA Nom): 85.5%
• Guaranteed Efficiency: 82.5%
• Power Factor (Nom PF): 73.7%
• Maximum KVAR: 7
• Voltage: 208-230/460V
• Full Load Amps (FLA): 3.1-3.0/1.5
• Service Factor Amps (SFA): 3.4/1.7
• Design Code: M

Section 2: 50 Hz Operation:

• Horsepower (HP): 1
• Speed (RPM): 1435
• Service Factor (SF): 1.00
• Efficiency (NEMA Nom): 83.7%
• Guaranteed Efficiency: 80.0%
• Power Factor (Nom PF): 80.1%
• Maximum KVAR: 6
• Voltage: 190/380V
• Full Load Amps (FLA): 3.4/1.7
• Design Code: K

Label Information:

• Inverter Suitable: 20:1 VT & 4.1 CT NEMA Premium
• ID: D 01 1128763-0011 M 0031
• Label Code: 483945

Key Features:

• High Efficiency: NEMA Premium efficiency rating ensures reduced energy consumption and operating costs.
• Versatile Operation: Suitable for both 60 Hz and 50 Hz operations, allowing for international use.
• Robust Design: Built with high-quality materials and bearings for extended durability and reliability.
• Inverter Compatibility: Suitable for inverter duty applications with a 20:1 VT and 4.1 CT rating.

Applications:

• Industrial Machinery: Ideal for use in various types of industrial equipment requiring reliable and efficient motor performance.
• Pumps and Compressors: Suitable for driving pumps, compressors, and other heavy-duty machinery.
• HVAC Systems: Can be used in heating, ventilation, and air conditioning systems.
• Conveyors and Material Handling: Perfect for applications in conveyor systems and other material handling equipment.

Installation and Setup:

1. Preparation:
   • Ensure all components are available and the work area is clean.
   • Verify the power supply matches the motor’s voltage and phase requirements.
2. Mounting the Motor:
   • Secure the motor to the mounting surface using appropriate bolts and brackets.
   • Ensure the motor is properly aligned to the driven equipment to avoid undue stress on the shaft and bearings.
3. Electrical Connections:
   • Connect the motor to the power supply according to the wiring diagram provided in the motor’s manual.
   • Ensure all electrical connections are secure and insulated.
4. Initial Testing:
   • Perform a preliminary test to ensure the motor runs smoothly without unusual noises or vibrations.
   • Check the current draw to ensure it is within the specified range.
5. Operational Testing:
   • Operate the motor under load to verify its performance.
   • Monitor the motor’s temperature and efficiency during operation.

Maintenance Tips:

• Regular Inspection: Periodically inspect the motor for signs of wear, especially on bearings and electrical connections.
• Lubrication: Ensure the bearings are properly lubricated according to the manufacturer’s recommendations.
• Cleaning: Keep the motor clean and free from dust and debris to ensure efficient cooling.
• Performance Monitoring: Regularly monitor the motor’s performance metrics, such as current draw and temperature, to detect any potential issues early.

Safety and Compliance:

• Handling: Handle the motor carefully to avoid damaging the bearings and internal components.
• Electrical Safety: Ensure all electrical work complies with local codes and standards.
• Protective Equipment: Use appropriate personal protective equipment (PPE) when handling and installing the motor.

Conclusion:

The Dayton 48ZJ83 Industrial Motor is a high-efficiency, versatile motor suitable for a wide range of industrial applications. Its robust construction, combined with NEMA Premium efficiency and inverter compatibility, makes it an excellent choice for reliable and energy-efficient performance. Proper installation and regular maintenance will ensure long-term reliability and optimal performance.
