FG-730 IntelliSense Dual Flex-Guard Audio Glass-Break Detector

$59.16

FG730 , ,

FG-730 IntelliSense Dual Flex-Guard Audio Glass-Break Detector

New: A brand-new, unused, undamaged item in its original packaging.

Description:
FG-730 from IntelliSense are dual technology glass-break detector that use flex detection and audio discrimination to detect breaking glass.
The flex and audio technologies are sensitive to different frequencies. The flex technology is sensitive to ultra low frequencies, the type generated by a blow to a glass window. The audio technology detects the frequency of breaking glass.
The audio technology remains off until the flex technology detects a blow to the glass. For an alarm condition to occur, the audio must detect the frequency of breaking glass within a defined time-window after the flex detects a blow to the glass. False alarms are virtually eliminated.
FEATURES
– Dual flex/audio technology
– Low 10 – 14 VDC operation
– Low 25 mA at 12 VDC current draw
– Adjustment on flex detection to fit characteristics of each location
– Alarm memory
– Indicator LEDs
– Energized form C alarm relay
– Circuit protection
– Cover tamper switch
– Noise burst rejection circuit
– RFI immunity
– UL listed

Specifications:
SPECIFICATIONS:
Range: FG-730 30′ (9 m)
Alarm relay: Form C 500 mA max 30 VDC max
Tamper switch: Form A (NC) 50 mA, 30 VDC
Power requirements: 10 – 14 VDC 25 mA, 12 VDC
Dimensions: 3.9″ H x 2.4″ W x 0.79″ D (98 mm x 61.5 mm x 20 mm)
Weight: 3 oz (85 g)
Operating temperature: 32 to 120 F (0 to 49 C)

NL25 E2

Weight 0.4 lbs
Dimensions 4 × 3 × 1.5 in
