Lennox CH33-24/30A-2F-2, Horizontal, Indoor Coil, 2/2.5 Ton, 14-1/2 in., Cased, RFC Valve

$120.00

Click to buy

Add to Wishlist
Compare
,

Lennox CH33-24/30A-2F-2, Horizontal, Indoor Coil, 2/2.5 Ton, 14-1/2 in., Cased, RFC Valve

Description:
CH33 Indoor Coils CH33-24/30A-2F
Minimal air resistance for better performance
– 1.5 to 5-ton capacities
– Cased
– Horizontal configuration
– Large-face area coil allows for high efficiency operation
– Copper-rifled tubing and enhanced aluminum fins improve transfer
– Long lasting, painted galvanized cabinet and plastic drain pans
Specifications:
Brand: Lennox
Catalog Number: 76L03
Model/Part Number: CH33-24/30A-2F
Minimum Order Quantity: 0.0
Base Unit of Measure: Unit(S)
Coil Cab Height: 14.5
Coil Cab Width: 21.5
Coil Cab Length: 26.5
Coil Cab Weight: 42
Product Depth: 21.5 IN
Product Height: 14.5 IN
Product Width: 26.5 IN
Configuration: Dedicated Horizontal
Liquid Line: 3/8 IN
Refrigerant: R-410A
Type: A-Shape
Cased: Cased
Return Opening: 13.375 x 20.375 IN
Supply Opening: 13 x 20 IN
Tonnage: 2.5-3
Gross Weight: 42 LB
Suction Line: 3/4 IN
Family : CH33
Cooling Capacity: 2.5 Ton Cooling
Material: Copper Coil
Valve: A-Shape, R-410A, Requires RFC Orifice or Expansion Valve
Dimensions: 14.5 x 26.5 x 21.5

Not Tested, maybe used

Dimensions 16 × 28 × 23 in
