Sheffield 1000 Visual Optical Comparator 110v

Sheffield 1000 Visual Optical Comparator 110v

The Sheffield 1000 Visual Optical Comparator is a precision measuring instrument that is commonly used in manufacturing and quality control applications. It is designed to measure the dimensional accuracy of small parts, such as machine components, stamped parts, and other manufactured items.
Condition: used. Tested, working.

The main advantage of the Sheffield 1000 is its ability to measure very small dimensions with a high degree of accuracy. This is achieved using a high-quality optical system that provides a clear and magnified view of the part being measured. The instrument is also very easy to use, and its digital readout and intuitive controls make it accessible to operators of all skill levels.

The specifications for the Sheffield 1000 Visual Optical Comparator 110v include:

• Magnification: 10x, 20x, 25x, 31.25x, 50x, 62.5x, and 100x
• Screen Diameter: 12 inches (300 mm)
• Maximum Part Height: 4.5 inches (115 mm)
• Maximum Part Weight: 22 pounds (10 kg)
• X-Y Stage Travel: 6 x 3 inches (150 x 75 mm)
• Digital Readout Resolution: 0.0001 inch (0.002 mm)
• Power Supply: 110V, 50/60 Hz

In summary, the Sheffield 1000 Visual Optical Comparator is a high-precision instrument that is used for measuring the dimensional accuracy of small parts in manufacturing and quality control applications. Its main advantages are its accuracy, ease of use, and versatility, which make it a popular choice for a wide range of industries.
