System Sensor SR Strobe STD CD, Red, Wall Mount, FIRE Lettering, Standard Candela

System Sensor SR Strobe STD CD, Red, Wall Mount, FIRE Lettering, Standard Candela

New: A brand-new, unused, undamaged item in its original packaging.

Description:
– Plug-in design with minimal intrusion into the back box
– Tamper-resistant construction
– Automatic selection of 12- or 24-volt operation at 15 and 15/75 candela
– Field-selectable candela settings on wall units: 15, 15/75, 30, 75, 95, 110, 115, 135, 150, 177, and 185
– Horn rated at 88+ dBA at 16 volts
– Rotary switch for horn tone and three volume selections
– Universal mounting plate for wall units
– Mounting plate shorting spring checks wiring continuity before device installation
– Electrically Compatible with legacy SpectrAlert devices
– Compatible with MDL sync module
– Listed for ceiling or wall mounting

Specifications:
Standard Operating Temperature: 32°F to 120°F (0°C to 49°C)
Humidity Range: 10 to 93% non-condensing
Strobe Flash Rate: 1 flash per second
Nominal Voltage: Regulated 12 DC/FWR or regulated 24 DC/FWR1
Operating Voltage Range2: 8 to 17.5 V (12 V nominal) or 16 to 33 V (24 V nominal)
Input Terminal Wire Gauge: 12 to 18 AWG
Wall-Mount Dimensions (including lens): 5.6˝ L × 4.7˝ W × 2.5˝ D (142 mm L × 119 mm W × 64 mm D)
Horn Dimensions: 5.6˝ L × 4.7˝ W × 1.3˝ D (142 mm L × 119 mm W × 33 mm D)
Wall-Mount Back Box Skirt Dimensions (BBS-2, BBSW-2): 5.9˝ L × 5.0˝ W × 2.2˝ D (151 mm L × 128 mm W × 56 mm D)
Brand: System Sensor
Model: SR
SKU: SR
UPC: 783863028076
